Important Warning
WHEN INSTALLING THE TACTICAL LIGHT, REPLACING THE BATTERY, CLEANING, OR PERFORMING MAINTENANCE, ALWAYS STRICTLY FOLLOW SAFETY RULES.

Mounting
The GL30R comes with two standard Picatinny rail (MIL-STD-1913) mount kits and one Multi Rail Mount System kit for flexible installation at any position on the rail*.
The included AER-07 also comes with one Picatinny rail (MIL-STD-1913) mount kit and one Multi Rail Mount System kit for flexible installation at any position on the rail*. After connecting the AER-07 to the GL30R, rotate its plug to lock it securely.
*For optimal performance, please ensure that all screws are fully tightened during installation.

Operating Instructions
The GL30R tactical light can be controlled by either its tactical tail switch or the included AER-07 tactical remote pressure switch.
GL30R Tactical Tail Switch

Fully press the tactical tail switch to turn on/off the tactical light*.
With the light turned off, tap the tactical tail switch to momentarily turn on the tactical light, release it and the tactical light will go out.
*When the GL30R is turned on with the tactical tail switch, it cannot be turned off with the AER-07 tactical remote pressure switch.


AER-07 Tactical Remote Pressure Switch
The AER-07 features a side locking slider. Press the slider according to the markings to lock or unlock both switches. Once the AER-07 is locked, both switches are disabled to prevent accidental activation.
Switch 1 is a forward-clicky switch and Switch 2 is a silent switch:
Single click the Switch 1 to turn on/off the tactical light*.
With the light turned off, single click the Switch 2 to momentarily turn on the tactical light, release it and the tactical light will go out.
*When the GL30R is turned on with the AER-07 tactical remote pressure switch, it cannot be turned off with its tactical tail switch. Disconnect the AER-07 tactical remote pressure switch to turn off the GL30R.

Battery Specifications

Warning: *18650 Li-ion batteries are powerful cells designed for commercial applications and must be treated with caution and handled with care. Using low-quality batteries or mishandling batteries (such as short-circuiting or overheating) could lead to combustion and jeopardize the safety of users and property. Any adverse effects resulting from the use of low-quality batteries are not covered by any Fenix warranty or liability.

Battery Replacement
Unscrew the light head and insert the battery with the anode side (+) towards the light head, then screw the light head back on.

Charging

1. Turn off the tactical light and remove the tactical remote pressure switch, then connect the USB Type-C end of the charging cable to the light.
2. The indicator will display red while charging and will turn green when fully charged.
3. With the light turned off, the normal charging time of the Fenix ARB-L18-3400 is approximately 2 hours from depleted to fully charged with a 5 V/3 A charging adapter.
4. Power specifications:
   • Charging voltage: 5 V
   • Maximum charging power: 12 W (5 V/2.4 A)
   • This tactical light does not support fast charging.
   • Only use a certified USB charging adapter that complies with the government safety standards of the country or region where this product is sold.
   *Do not charge while using two CR123A batteries.

Battery level indication
Each time the tactical light is turned on, the indicator will indicate the battery level and will last for 3 seconds.

• Green light on: 100% - 85%
• Green light flashes: 85% - 50%
• Red light on: 50% - 25%
• Red light flashes (6Hz): 25% - 1%

*This only works with a Fenix ARB-L18 series battery.

Intelligent Overheat Protection
The tactical light will accumulate a lot of heat when used for extended periods. When the tactical light reaches a temperature of 60°C/140°F or above, the tactical light will automatically step down a few lumens to reduce the temperature. When the temperature drops below 60°C/140°F, the tactical light automatically recalls the preset output level.

Low-voltage Warning
When the voltage level drops below the preset level, the tactical light will gradually decrease output level accordingly. When the voltage level is still too low, the battery level indicator will blink rapidly to remind users to recharge or replace the battery in a timely manner.
*This only works with a Fenix ARB-L18 series battery.

Usage and Maintenance

• Disassembling the sealed head can cause damage to the tactical light and will void the warranty.
• Fenix recommends using an excellent quality battery.
• If the tactical light will not be used for an extended period, remove the battery, or the tactical light could be damaged by electrolyte leakage.
• Clean the lens regularly to maintain the tactical light's performance.
• Long-term use can result in O-ring wear. To maintain a proper water seal, replace the ring with an approved spare.
• Since platform maintenance requires the use of organic solvents, organic solvents contaminating key internal components of the tactical light may cause malfunctions, and the tactical light will not receive normal warranty service.
• Periodic cleaning of the tactical light and battery contacts improves the tactical light's performance as dirty contacts may cause the tactical light to flicker, shine intermittently or even fail to illuminate for the following reasons:
  A: Poor battery level.
  Solution: Recharge or replace the battery.
  B: The contact or contact point of the battery or tactical light is dirty.
  Solution: Clean the contact points with a cotton swab soaked in rubbing alcohol.

If the above methods don't work, please contact the distributor.


Warning

• Do NOT place this tactical light in the reach of children!
• Do NOT shine this tactical light directly into the eyes of anyone!
• Do NOT place light head near flammable objects, high temperatures can cause objects to overheat and become flammable/ignite!
• Do NOT use this tactical light in inappropriate ways such as holding the unit in your mouth, doing so could cause serious personal injury or death if the tactical light or internal battery fails!
• This tactical light will accumulate a significant amount of heat while operating, resulting in a high temperature of the light shell. Pay close attention to avoid burns!
• Remove the battery or loosen the light head to prevent accidental activation when the tactical light is placed in a closed and flammable environment such as pockets and backpacks!
• The LED of this tactical light is not replaceable; so the whole tactical light will need to be replaced when the LED reaches the end of its lifespan.


What are the key features of GL30R?
A: The Fenix GL30R is a high-output long-distance tactical light that delivers a maximum output of 800 lumens, a maximum beam intensity of 100,000 candela, and a maximum beam distance of 630 meters. Its key features include:

1. Powered by the included ARB-L18-3400 rechargeable battery. Also compatible with two CR123A batteries.
2. Compatible with the included AER-07 tactical remote pressure switch.
3. Compatible with mainstream rail systems and can be paired according to your specific model.

What kind of LED is used in GL30R? Does Fenix offer to replace the LED?
A: A Luminus SFT12R LED with a lifespan of 50,000 hours. Fenix does not provide LED replacement services for the time being, and users are not recommended to replace the LEDs independently, which may affect product performance and cause product damage.

What is the color temperature of GL30R?
A: Around 7500K.

What is the working voltage of GL30R?
A: 3.0 V - 6.6 V.

Is GL30R rechargeable? How long is the charging time?
A: The GL30R features a charging port and supports USB Type-C charging. The normal charging time of the Fenix ARB-L18-3400 is approximately 2 hours from depleted to fully charged*.
*Do not charge while using two CR123A batteries.

How to prevent accidentally activating the GL30R?
A: Unscrew the light head a few turns to prevent accidental activation.

Why does the GL30R step down a few lumens after being used for a while?
A: There are two reasons:

1. Intelligent Overheat Protection
   The light will accumulate a lot of heat when used for extended periods. When the light reaches a temperature of 60°C or above, the light will automatically step down a few lumens to reduce the temperature.
2. Low-voltage Downshift
   When the voltage level drops below the preset level, the light will gradually decrease output level accordingly. When the voltage level is still too low, the battery level indicator will blink rapidly to remind users to recharge or replace the battery in a timely manner.
   *This only works with a Fenix ARB-L18 rechargeable series battery.

Why does the GL30R happen to flicker?
A: The reasons that may cause the light to flicker, shine intermittently or even fail to illuminate:

1. Poor battery level.
   Solution: Recharge or replace the battery.
2. The contact or contact point of the battery or light is dirty.
   Solution: Clean the contact points with a cotton swab soaked in rubbing alcohol.

If the above methods don't work, please contact your authorized distributor.

What kind of battery can be used in GL30R?
A: It is recommended to use a Fenix ARB-L18-3400 V3.0 battery. The GL30R is also compatible with two CR123A batteries. Other Li-ion batteries are not recommended. As an unmatched battery may cause the light to fail to work normally.

What should I do when the GL30R needs repair?
A:

1. 15-day replacement: Fenix will replace identical or equal products with documented manufacturing defects within 15 days of purchase.
2. 5-year free repair: Fenix will repair a light free of charge within 5 years (rechargeable battery and other accessories: 1 year) of purchase if problems develop with normal use.
3. Lifetime limited warranty: If repair is required after 5 years from the date of purchase, Fenix will charge for parts. The total repair fee is dictated by the cost of the replaced materials.
4. If you need warranty service, fill out the warranty form at https://www.fenixlighting.com/pages/warranty-repairs to start your repair claim.
