Fenix HM65R-T Rechargeable Headlamp - DISCONTINUED

$137.00 $104.95

Shipping calculated at checkout.

Max Lumens:


18650 or CR123A
View Details

For commercial orders and large purchases, contact us at (888) 775-9996 x6 or GET A QUOTE

WARNING. Be aware of counterfeit Fenix merchandise in the U.S. marketplace. READ MORE >>

SKU: HM65RTBKN/ABarcode: 6942870307718N/A

Product Overview

The Fenix HM65R-T Headlamp is a new version of the best selling HM65R Headlamp that features slightly improved performance with its Luminus SST40 LEDs and a new patented headband fit system. Independently controlled spotlight and a floodlight produce a combined maximum 1500 lumens of neutral and white light. Powered by the included 3400mAh battery, this headlamp is USB-C rechargeable and includes a battery level indicator. It is made of a magnesium alloy for better strength, impact resistant to 2 meters (6.6ft), and less weight. Perfect for all activities where the brightest hands-free lighting is required.


Max Lumens: 1500
Max Beam Distance: 558 Feet (170 meters)
Max Runtime: 300 hours
Lighting Modes: 3 brightness levels on spotlight, and 3 brightness levels on floodlight
Bulb Type: Uses Luminus SST40 white and Cree XP-G2 S3 neutral white LEDs
Size: Length: 3.15” (80mm) Width: 1.85” (47mm) Height: 1.54” (39mm)
Weight: 3.21 oz. (91g) excluding battery
Battery: One included 18650 rechargeable Li-ion battery or two CR123A batteries
Included: ARB-L18-3400 rechargeable li-ion battery, USB Type-C charging cable, spare O-ring
Warranty: Limited Lifetime Guarantee from Fenix Lighting USA

More Information

  • Uses Luminus SST40 white and Cree XP-G2 S3 neutral white LEDs, with a lifespan of 50,000 hours
  • Constant current circuit ensures longer runtimes
  • Reverse polarity protection to protect from improper battery insertion
  • Dual top switched operate an independent spotlight and floodlight
  • USB Type-C charging port for fast charging
  • Patented rotary press/pull clasp, headband can be adjusted with a single hand
  • Made from quality aluminum, magnesium and PC—lightweight and durable

*The maximum head size the SPORT headband will fit is 24" (61cm) or hat size 7 5/8.

Fenix HM65R-T Rechargeable Headlamp - DISCONTINUED specs chart


Fenix HM65R-T Rechargeable Headlamp - DISCONTINUED runtime chart


Spotlight: for on/off, mode switching, lockout function and output selection on spotlight mode.

Floodlight: for on/off, mode switching, lockout function and output selection on floodlight mode.



Press and hold either of the two switches for 0.5 seconds to turn on/off the lamp. Low output level is set by default.


Mode switching

Press and hold either of the two switches for 0.5 seconds to reach the corresponding mode. The two modes are separately controlled.


Output selection

Spotlight mode: single click the spotlight switch to cycle through Low→Med→High.

Floodlight mode: single click the floodlight switch to cycle through Low→Med→High.


Lockout Function

Lock: With the lamp switched off, press and hold either of the two switches, or simultaneously press the two switches for 3 seconds, the lamp will blink 4 times on Low of floodlight mode to indicate locked status.

Unlock: With the lamp is locked, simultaneously press the two switches for 3 seconds, the lamp will be activated with 4 one-second blinks and activates on Low of floodlight mode. In locked status, clicking or pressing the switches will activate 4 one-second blinks on Low of floodlight mode to indicate locked status.


Battery Specifications

TypeDimensionsNominal voltageUsability
Fenix ARB-L18 Series186503.6 V /3.7 VRecommended√√
Non-rechargeable Battery (Li-ion)CR123A3VUsable
Rechargeable Battery (Li-ion)186503.6 V /3.7 VCaution*
Rechargeable Battery (Li-ion)163403.6 V /3.7 VBanned×

*18650 Li-ion batteries are powerful cells designed for commercial applications and must be treated with caution and handled with care. Only use quality batteries with circuit protection will reduce the potential for combustion or explosion; but cell damage or short circuiting are potential risks the user assumes.


Quality Li-ion battery with protective circuit will reduce risks. Fenix ARB-L18 Series battery is recommended.


Battery Replacement

Unscrew the battery cover anticlockwise to insert the battery with the anode side (+) towards the inner side, then screw the battery cover back on.



  1. Uncover the anti-dust cap and plug the USB Type-C side of the charging cable into the charging port of the
  2. The normal charging time of the Fenix ARB-L18-3500 rechargeable Li-ion battery is about 3 hours with the lamp being switched off. When charging, Low output of spotlight or floodlight mode can be separately selected. The headlamp will not automatically power on after full charging.
  3. In charging process, one indicator flashes: below 20%, one constant-on and one flashes: 20% - 50%, two constant-on and one flashes: 50% - 80%, three constant-on and one flashes: 80% - 95%, four constant-on: charging complete.
  4. Replace the anti-dust cap to ensure waterproof and dustproof ability.

Battery Level Indication

With the lamp is switched off, single click either of the two switches to check the battery status, the indicator(s) will last for 3 seconds. There will be no response with the lamp locked.

  • Four lights on: 100% - 80%
  • Three lights on: 80% - 60%
  • Two lights on: 60% - 40%
  • One light on: 40% - 20%
  • One light flashes: 20% - 0%

Note: This only works with Fenix ARB-L18 Series 18650 rechargeable Li-ion battery.


Intelligent Overheat Protection

The lamp will accumulate a lot of heat when used on high, med and low output levels for extended periods. When the lamp reaches a temperature of 65°C or above, the lamp will automatically step down a few lumens to reduce the temperature. When the temperature drops below 65°C, it will then allow the user for the reselection of the modes.


Low-voltage Warning

When the voltage level drops below the preset level, the headlamp is programmed to downshift to a lower brightness level until Low output is reached. When this happens in Low output mode, one of the battery level indicators blinks to remind you to timely recharge or replace the battery.


Note: This only works with Fenix ARB-L18 Series 18650 rechargeable Li-ion battery.


Headband Assembly

Notice: The headband is factory assembled by default.


Headband Adjustment

Pull the rotary clasp up to unlock, and pull on the attached end of the headband to loosen. Press the rotary clasp back into its down position and rotate it clockwise to tighten the headband.


Usage and Maintenance

  • Disassembling the sealed head can cause damage to the lamp and will void the warranty.
  • Fenix recommends using an excellent quality Fenix 18650 battery.
  • If the lamp will not be used for an extended period, remove the battery, or the lamp could be damaged by electrolyte leakage.
  • Lock the lamp or take out the battery to prevent accidental activation during storage or transportation.
  • Long-term use can result in O-ring wear. To maintain a proper water seal, replace the ring with an approved spare.
  • Periodic cleaning of the battery contacts improves the lamp's performance as dirty contacts may cause the lamp to flicker, shine intermittently or even fail to illuminate for the following reasons:

A: The battery needs replacing.

Solution: Replace battery (Ensure battery is inserted according to the manufacturer’s specifications).

B: The threads, PCB board contact or other contacts are dirty.

Solution: Clean the contact points with a cotton swab soaked in rubbing alcohol. If the above methods don't work, please contact the distributor.



  • The headlamp is a high-intensity lighting device capable of causing eye damage to the user or others. Avoid shining the lamp directly into anyone’s eyes.
  • This headlamp will accumulate a lot of heat when used for extended periods, resulting in high temperature of the headlamp Pay attention to safe use to avoid scalding.
  • All information provided in this manual is subject to change without prior notice.

AQs about Fenix HM65R-T Headlamp


Q1. What is the product positioning of HM65R-T? And who are the target customers?

A: The Fenix HM65R-T rechargeable headlamp is designed for tail running. This new Fenix headlamp is constructed from ultra lightweight magnesium material. With two LED's, the HM65R-T can reach 1500 lumens by activating its dual spotlight and floodlight mode with the separately controlled top switches. The primary power option is a single 18650 battery; as a secondary option, you can also power the HM65R-T with two CR123A batteries. The HM65R-T also features an USB Type-C charging port to facilitate charging of the included 18650 battery. With an all-new body designed from magnesium, the Fenix HM65R-T headlamp has an IP68 rated protection, and 2 meters of impact resistance. The included hollow headband provides comfort and adjustability for a perfect fit in every situation. It is recommended using the Fenix HM65R-T for trail running trips where you will need to light your path quickly and hands-free.


Q2. What are the key features and benefits of HM65R-T?

A: 1) Separately controlled spotlight and floodlight

2) 24-hour runtime mode for trail running.

3) Made of quality magnesium, which only weighs 91 grams

4) SPORT headband fit system, headband can be adjusted with a single hand

5) User-friendly design for comfortable use and wear.


Q3. Why does the maximum output only reach 1500 lumens when spotlight and floodlight are simultaneously turned on on High?

A: As a general rule, the maximum output should be 1700 lumens = 1300 lumens (Spotlight High) + 400 lumens (Floodlight High); while the actual maximum output is 1500 lumens due to limited battery power when the two light s are simultaneously turned on.


Q4. Can the HM65R-T be turned on while charging?

A: Yes. Low output of spotlight or floodlight mode can be separately selected. The headlamp will not automatically power on after full charging.


Q5. What kind of LED's are used in HM65R-T?

A: Luminus SST40 white and Cree XP-G2 S3 neutral white LED's.


Q6. What is the so-called 24-hour trail running mode?

A: It is the Low output of spotlight that delivers 130 lumens for 24 hours, the brightness and runtime are very suitable for night trail running illumination.


Q7.  Is the HM65R-T battery port waterproof?

A. The light is waterproof so long as the battery port cover is in place.


Q8.  What should I do if the HM65R-T needs repair?

A: 1. 15-day replacement: Fenix will replace identical or equal products with documented manufacturing defects within 15 days of purchase.

2. 2-year free repair: Fenix will repair a light free of charge within 2 years of purchase if problems develop with normal use.

3. Lifetime maintenance: If repair is required after 2 years from the date of purchase, Fenix will charge for parts. The total repair fee is dictated by the cost of the replaced materials.

4. If you need warranty service, fill out the warranty form at https://www.fenixlighting.com/pages/warranty-repairs to start your repair claim.
